Auto Repairing Type Speed Door
Feature
- Stability
In the event of a vehicle crash, the door restores automatically to minimize damage. - Hermeticity
By minimizing the gap between the door sheet and the rail track, indoor pollution due to inflow of outside air is relatively low. - Counterbalance
Since it is not gravity, it operates smoothly without noise and abnormal operation when driven. - Safety
There is no risk of accidental fall, and you can avoid serious damage even if you crash when you descend.
-
Product Specifications
| Category | Specifications |
|---|---|
| Door Curtain | Soft PVC + Fabric 0.9T - transparent window: PVC transparent 2.0T Flexible PVC |
| Motor | Geared motor (0.75~2.2Kw) |
| Door Rail | AL extrudate + UHMWPE |
| Operating Speed |
Open(Max) - 2.0m/sec Close(Max) 一 2.0m/sec |
| Detection | Loop, Remote Control, infrared, etc. available for selection |
| Cover | SUS hairline (1.2T) - stainless steel plated.2T) |
-
Sheet Comparison
| Thickness | 0.9mm | 2.0mm |
|---|---|---|
| Flame Resistance | Grade 1 | None |
| Advantages | Softness and degree of utilization | Less creasing |
| Disadvantages | Can be damaged by sharp objects | Hardens in low temperatures |
| Weight | 1kg/㎡ | 2kg/㎡ |
